| Viewing angle L/R |
50° / 50° |
| H/L |
20° / 40° |
| Display resolution |
1024 x 768 @ 75Hz |
| Horizontal frequency |
30~60 KHz |
| Vertical frequency |
50~75 Hz |
| Display colors |
262K colors (depends on panel) |
| Contrast |
250:1 |
| Brightness |
150 cd/m2 |
| Input signal |
Analog RGB (0.7 Vp-p , 75 ohms ) |
| Plug & play |
DDC 1/2B |
| External connections |
15 pin D-sub |
| Input terminals |
DC 12V jack |
| OSD languages |
Multi-languages |
| User controls |
Power key , Menu/+/-/Auto key |
| Power management |
VESA DPMS |
| Power consumption-working |
18W max. |
| Power consumption-standby |
< 3W |
| Power supply(adapter) |
AC 100~ 240 V , 50~60 Hz . DC 12V/3A |
| Operation temperature |
0~40°C |
| Operation humidty |
Less than 85% |
| Dimension |
398 x 375 x 150 mm |
| Weight ( N.W. ) |
3.8Kg ( including accessories) |
